ABB Saco 16D1 数字报警器单元 Saco16D1

Description

ABB Saco 16D1 Digital Annunciator Unit 技术参数及中英文介绍

1. Product Overview 产品概述

• 中文
  ABB Saco 16D1 数字报警器单元是一款高度集成的工业报警与状态监控设备，适用于电力系统、自动化控制、过程工业等领域。该设备支持多通道信号输入、自定义报警逻辑及远程通信功能，能够实时监测设备状态并触发报警信号，提升系统安全性与可靠性。
• English
  The ABB Saco 16D1 Digital Annunciator Unit is a highly integrated industrial alarm and status monitoring device designed for power systems, automation control, and process industries. It supports multi-channel signal input, customizable alarm logic, and remote communication capabilities, enabling real-time equipment status monitoring and alarm triggering to enhance system safety and reliability.

2. Key Technical Parameters 关键技术参数

Parameter 参数	Specification 规格
Input Channels 输入通道数	16 Channels (可扩展至32通道，需配置扩展模块)
	16 Channels (Expandable to 32 channels with additional modules)
Input Type 输入类型	Dry Contact (干接点) 或 Wet Contact (湿接点)，支持24V DC/110V DC/220V AC 信号输入
	Dry/Wet Contact, supporting 24V DC/110V DC/220V AC signal inputs
Alarm Output 报警输出	16 Relay Outputs (继电器输出，支持常开/常闭触点)
	16 Relay Outputs (Supporting normally open/normally closed contacts)
Display Type 显示类型	High-Contrast LCD Display (高对比度液晶显示屏，支持中文/英文菜单)
	High-contrast LCD display with Chinese/English menu support
Communication Interface 通信接口	RS-485 (Modbus RTU协议)，支持以太网扩展（可选）
	RS-485 (Modbus RTU protocol), Ethernet expansion optional
Power Supply 电源供应	85V AC to 264V AC 或 20V DC to 60V DC (宽电压范围)
	85V AC to 264V AC or 20V DC to 60V DC (Wide voltage range)
Operating Temperature 工作温度	-20°C to +60°C (工业级宽温设计)
	-20°C to +60°C (Industrial-grade wide temperature range)
Humidity 湿度	5% to 95% RH (无冷凝)
	5% to 95% RH (Non-condensing)
Protection Grade 防护等级	IP54 (适用于机柜安装，防尘防溅水)
	IP54 (Suitable for cabinet installation, dustproof and splash-proof)
Mounting 方式	DIN Rail Mounting (35mm标准导轨安装)
	DIN Rail Mounting (35mm standard rail)
Approvals & Certifications 认证	CE, UL, cUL, IEC 61850 (符合国际安全标准与电力系统通信协议)
	CE, UL, cUL, IEC 61850 (Compliant with international safety standards and power system communication protocols)

3. Features & Advantages 产品特点与优势

• 多通道报警与状态监控
  支持16路独立输入通道，可配置为报警输入或状态监测，适用于复杂工业场景。
  Multi-channel Alarm & Status Monitoring
  16 independent input channels configurable for alarm or status monitoring, suitable for complex industrial scenarios.

• 灵活的报警逻辑与输出
  用户可通过软件自定义报警阈值、延时时间及输出逻辑，支持逻辑“与”“或”组合。
  Flexible Alarm Logic & Output
  Customizable alarm thresholds, delay times, and output logic via software, supporting logical “AND”/”OR” combinations.

• 远程通信与数据记录
  内置RS-485接口，支持Modbus RTU协议，可与SCADA系统或PLC无缝集成；支持历史报警数据记录与导出。
  Remote Communication & Data Logging
  Built-in RS-485 interface with Modbus RTU protocol for seamless integration with SCADA/PLC systems; supports historical alarm data logging and export.

• 高可靠性设计
  采用工业级元器件，支持宽温范围、抗电磁干扰（EMI）及防雷击保护，确保在恶劣环境下稳定运行。
  High Reliability Design
  Industrial-grade components support wide temperature range, EMI immunity, and lightning protection for stable operation in harsh environments.

• 用户友好界面
  高对比度液晶显示屏支持中文/英文菜单，操作简便；支持密码保护与权限管理，防止误操作。
  User-Friendly Interface
  High-contrast LCD display with Chinese/English menus for easy operation; supports password protection and permission management to prevent misuse.

4. Applications 应用场景

• 电力系统监控
  用于变电站、发电厂的开关量信号监测与报警，如断路器状态、保护装置动作等。
  Power System Monitoring
  Monitoring and alarming for switching signals in substations and power plants (e.g., circuit breaker status, protection device actions).

• 工业自动化
  适用于PLC/DCS系统的报警与状态反馈，如设备故障、液位/压力超限等。
  Industrial Automation
  Alarm and status feedback for PLC/DCS systems (e.g., equipment faults, level/pressure overruns).

• 过程控制
  在石化、冶金等流程工业中，用于关键设备状态监控与联锁保护。
  Process Control
  Critical equipment status monitoring and interlock protection in petrochemical and metallurgical industries.

• 智能建筑
  用于楼宇自动化系统中的消防报警、安防监控等场景。
  Intelligent Buildings
  Fire alarming and security monitoring in building automation systems.

5. Conclusion 总结

ABB Saco 16D1 数字报警器单元是一款高性能、高可靠性的工业报警与状态监控设备，适用于多种工业自动化场景。其灵活的报警逻辑、远程通信能力及高防护等级，使其成为工业控制系统的理想选择。

The ABB Saco 16D1 Digital Annunciator Unit is a high-performance, industrial-grade device suitable for various automation applications. Its flexible alarm logic, remote communication capabilities, and high protection rating make it an ideal choice for industrial control systems.

如需进一步的技术支持或定制化解决方案，请联系ABB官方授权代理商或技术团队。
