ABB DSDI 110A 57160001-AAA 数字输入模块

Description

ABB DSDI 110A Digital Input Module (57160001-AAA) Technical Parameters

中英文技术参数及产品介绍

1. DSDI 110A 57160001-AAA Product Overview 产品概述

• 中文
  ABB DSDI 110A 数字输入模块（型号：57160001-AAA）是一款高性能的工业自动化输入模块，专为分散控制系统（DCS）和可编程逻辑控制器（PLC）设计。该模块适用于高可靠性、高抗干扰的工业环境，支持24V DC数字信号输入，广泛应用于电力、石化、冶金、造纸等行业。
• English
  The ABB DSDI 110A Digital Input Module (Part No. 57160001-AAA) is a high-performance industrial automation input module designed for Distributed Control Systems (DCS) and Programmable Logic Controllers (PLC). It is suitable for high-reliability and high-noise-immunity industrial environments, supporting 24V DC digital signal inputs. It is widely used in industries such as power generation, petrochemicals, metallurgy, and papermaking.

2. DSDI 110A 57160001-AAA Key Technical Parameters 关键技术参数

Parameter 参数	Specification 规格
Input Type 输入类型	24V DC Digital Input (干接点或湿接点，支持源型/漏型输入)
	24V DC Digital Input (Dry/Wet Contact, Sourcing/Sinking Type)
Number of Channels 通道数	16 Channels (可扩展至32通道，需配置扩展模块)
	16 Channels (Expandable to 32 channels with additional modules)
Input Voltage Range 输入电压范围	18V DC to 30V DC (兼容24V DC标准工业电源)
	18V DC to 30V DC (Compatible with 24V DC standard industrial power supplies)
Input Current 输入电流	3mA (典型值，源型输入) / 4mA (典型值，漏型输入)
	3mA (Typical, Sourcing Type) / 4mA (Typical, Sinking Type)
Response Time 响应时间	≤1ms (信号从输入到输出的延迟时间)
	≤1ms (Delay from input to output)
Isolation Voltage 隔离电压	500V AC (通道间及通道与地之间)
	500V AC (Between channels and channel-to-ground)
LED Indicators LED指示灯	每个通道独立LED状态指示（绿色：信号正常；红色：故障）
	Individual LED indicators per channel (Green: Normal; Red: Fault)
Operating Temperature 工作温度	-20°C to +70°C (工业级宽温设计)
	-20°C to +70°C (Industrial-grade wide temperature range)
Storage Temperature 存储温度	-40°C to +85°C
	-40°C to +85°C
Humidity 湿度	5% to 95% RH (无冷凝)
	5% to 95% RH (Non-condensing)
Protection Grade 防护等级	IP20 (适用于机柜安装)
	IP20 (Suitable for cabinet installation)
Mounting 方式	DIN Rail Mounting (35mm标准导轨安装)
	DIN Rail Mounting (35mm standard rail)
Power Consumption 功耗	≤2W (典型值)
	≤2W (Typical)
Approvals & Certifications 认证	CE, UL, cUL, CCC (符合国际安全标准)
	CE, UL, cUL, CCC (Compliant with international safety standards)

3. Features & Advantages 产品特点与优势

• 高可靠性设计
  采用工业级元器件，支持宽温范围和抗电磁干扰（EMI）能力，确保在恶劣工业环境下稳定运行。
  High Reliability
  Industrial-grade components support wide temperature range and EMI immunity for stable operation in harsh environments.

• 灵活的输入配置
  支持源型（Sourcing）和漏型（Sinking）输入模式，兼容多种传感器和开关设备。
  Flexible Input Configuration
  Supports sourcing and sinking input modes, compatible with various sensors and switching devices.

• 快速响应与高精度
  响应时间≤1ms，适用于高速信号采集和实时控制场景。
  Fast Response & High Precision
  ≤1ms response time, suitable for high-speed signal acquisition and real-time control.

• 模块化与可扩展性
  支持热插拔和模块化扩展，便于系统维护和升级。
  Modular & Scalable Design
  Hot-swappable and modular expansion for easy maintenance and upgrades.

• 状态诊断与故障保护
  内置通道状态诊断功能，支持过压、过流、短路保护，确保系统安全。
  Status Diagnostics & Fault Protection
  Built-in channel diagnostics with overvoltage, overcurrent, and short-circuit protection.

4. DSDI 110A 57160001-AAA Applications 应用场景

• 工业自动化
  用于PLC/DCS系统的数字信号采集，如按钮、限位开关、传感器信号输入。
  Industrial Automation
  Digital signal acquisition for PLC/DCS systems (e.g., buttons, limit switches, sensor inputs).

• 电力监控
  适用于变电站、发电厂的开关量信号监测。
  Power Monitoring
  Monitoring of switching signals in substations and power plants.

• 过程控制
  在石化、冶金等流程工业中，用于设备状态监控和联锁保护。
  Process Control
  Equipment status monitoring and interlock protection in petrochemical and metallurgical industries.

• 智能楼宇
  用于楼宇自动化系统中的照明、空调等设备的状态反馈。
  Intelligent Buildings
  Status feedback for lighting, HVAC, and other equipment in building automation systems.

5. Conclusion 总结

ABB DSDI 110A 数字输入模块（57160001-AAA）是一款高性能、高可靠性的工业级输入模块，适用于多种工业自动化场景。其灵活的输入配置、快速响应能力和高防护等级，使其成为工业控制系统的理想选择。

The ABB DSDI 110A Digital Input Module (57160001-AAA) is a high-performance, industrial-grade input module suitable for various automation applications. Its flexible configuration, fast response, and high protection rating make it an ideal choice for industrial control systems.

如需进一步的技术支持或定制化解决方案，请联系ABB官方授权代理商或技术团队。
