GE Fanuc 869-EP5P5B5HSSALAGMPFBSENNBN2

Description

General Electric (GE) Multilin 869 电机保护继电器（型号：869-EP5P5B5HSSALAGMPFBSENNBN2）是一款专为中大型电机设计的高性能保护装置，属于 GE Multilin 8 系列平台的一部分。该产品广泛应用于石油、天然气、采矿、水泥、废水处理等行业，为电机提供全面的保护、监控和诊断功能。

---

主要功能与特点

1. 全面的电机保护：
   • 提供过载、欠载、接地故障、相不平衡、堵转、热过载等保护功能。
   • 支持同步电机和异步电机的保护，适用于双速、变频驱动（VFD）、循环加载等应用场景。
2. 先进的电机监测与诊断：
   • 实时监测电机的运行状态，包括电流、电压、温度、振动等参数。
   • 提供详细的故障记录和事件日志，便于故障分析和维护。
   • 支持预测性维护，通过趋势分析提前发现潜在问题。
3. 灵活的配置与可编程逻辑：
   • 提供广泛的定制化选项，用户可根据具体需求配置保护参数和逻辑。
   • 支持 FlexLogic 可编程逻辑，用户可自定义保护和控制功能。
4. 强大的通信与集成能力：
   • 支持多种通信协议，如 Modbus、DNP3、IEC 61850 等，便于与 SCADA 系统或其他自动化设备集成。
   • 提供 Wi-Fi 连接功能，简化系统配置和远程访问。
5. 高可靠性与安全性：
   • 采用坚固的设计和高质量的组件，确保在恶劣环境下的可靠运行。
   • 提供网络安全功能，符合 NERC CIP 标准，保护系统免受网络攻击。
6. 易于维护与测试：
   • 抽拔式设计，便于快速更换和测试，减少停机时间。
   • 提供详细的自检和诊断功能，简化维护流程。

---

应用场景

• 石油与天然气：用于压缩机、泵、风机等关键设备的保护。
• 采矿与金属：保护矿山提升机、输送带、破碎机等设备。
• 水泥与废水处理：用于水泥磨机、泵站、污水处理设备等。
• 其他行业：适用于任何需要中大型电机保护的工业应用。

---

技术规格

• 型号：869-EP5P5B5HSSALAGMPFBSENNBN2
• 保护功能：过载、欠载、接地故障、相不平衡、堵转、热过载等。
• 监测参数：电流、电压、温度、振动等。
• 通信协议：Modbus、DNP3、IEC 61850 等。
• 网络安全：符合 NERC CIP 标准。
• 设计：抽拔式，便于维护和测试。

---

优势

1. 全面的保护功能：覆盖电机运行中的各种故障类型，确保设备安全。
2. 先进的诊断能力：提供详细的故障记录和趋势分析，帮助用户提前发现潜在问题。
3. 灵活的配置：用户可根据具体需求定制保护参数和逻辑。
4. 强大的通信能力：支持多种通信协议，便于与现有系统集成。
5. 高可靠性与安全性：坚固的设计和网络安全功能确保系统稳定运行。
6. 易于维护：抽拔式设计和自检功能简化维护流程，减少停机时间。

---

总结

GE Multilin 869 电机保护继电器是一款功能强大、灵活可靠的保护装置，适用于中大型电机的全面保护、监控和诊断。其先进的功能和灵活的配置选项使其成为工业应用中的理想选择，特别是在需要高可靠性和安全性的关键设备中。

The General Electric (GE) Multilin 869 motor protection relay (model: 869-EP5P5B5HSSALAGMPFBSENNBN2) is a high-performance protection device designed specifically for medium to large motors and is part of the GE Multilin 8 series platform. This product is widely used in industries such as petroleum, natural gas, mining, cement, and wastewater treatment, providing comprehensive protection, monitoring, and diagnostic functions for motors.

Main functions and features
Comprehensive motor protection:
Provide protection functions for overload, underload, ground fault, phase imbalance, locked rotor, thermal overload, etc.
Supports protection for both synchronous and asynchronous motors, suitable for applications such as dual speed, variable frequency drive (VFD), and cyclic loading.
Advanced motor monitoring and diagnosis:
Real time monitoring of the operating status of the motor, including parameters such as current, voltage, temperature, vibration, etc.
Provide detailed fault records and event logs for easy fault analysis and maintenance.
Support predictive maintenance and identify potential issues in advance through trend analysis.
Flexible configuration and programmable logic:
Provide a wide range of customized options, allowing users to configure protection parameters and logic according to specific needs.
Supports FlexLogic programmable logic, allowing users to customize protection and control functions.
Powerful communication and integration capabilities:
Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., making it easy to integrate with SCADA systems or other automation devices.
Provide Wi Fi connectivity to simplify system configuration and remote access.
High reliability and safety:
Adopting robust design and high-quality components to ensure reliable operation in harsh environments.
Provide network security features that comply with NERC CIP standards to protect the system from network attacks.
Easy to maintain and test:
Pull out design for quick replacement and testing, reducing downtime.
Provide detailed self checking and diagnostic functions to simplify maintenance processes.
Application scenarios
Oil and natural gas: used for the protection of key equipment such as compressors, pumps, fans, etc.
Mining and Metals: Protecting equipment such as mine hoists, conveyors, crushers, etc.
Cement and wastewater treatment: used for cement mills, pump stations, sewage treatment equipment, etc.
Other industries: Suitable for any industrial application that requires protection for medium to large motors.
technical specifications
Model: 869-EP5P5B5HSSALAGMFBSENNN2
Protection functions: overload, underload, ground fault, phase imbalance, locked rotor, thermal overload, etc.
Monitoring parameters: current, voltage, temperature, vibration, etc.
Communication protocols: Modbus, DNP3, IEC 61850, etc.
Network security: Compliant with NERC CIP standards.
Design: Pull out type, easy to maintain and test.
advantage
Comprehensive protection function: covering various types of faults during motor operation to ensure equipment safety.
Advanced diagnostic capabilities: providing detailed fault records and trend analysis to help users detect potential problems in advance.
Flexible configuration: Users can customize protection parameters and logic according to specific needs.
Powerful communication capability: Supports multiple communication protocols, making it easy to integrate with existing systems.
High reliability and security: The robust design and network security features ensure stable system operation.
Easy to maintain: The pull-out design and self checking function simplify the maintenance process and reduce downtime.
summarize
The GE Multilin 869 motor protection relay is a powerful, flexible, and reliable protection device suitable for comprehensive protection, monitoring, and diagnosis of medium and large motors. Its advanced features and flexible configuration options make it an ideal choice for industrial applications, especially in critical equipment that requires high reliability and safety.
