ABB AX670 3BSE000566R1 Analog Mixed Module Technical Parameters (技术参数) 中英文介绍
1. Product Overview (产品概述)
- 中文:
ABB AX670 3BSE000566R1 是一款高性能模拟混合模块，适用于工业自动化系统中的模拟信号处理与混合控制应用。该模块支持多种模拟信号输入输出，具备高精度、高可靠性和强抗干扰能力，广泛应用于电力、冶金、化工、石油、天然气等工业领域，可集成于分布式控制系统（DCS）或可编程逻辑控制器（PLC）中，实现高效的数据采集与控制。 - English:
The ABB AX670 3BSE000566R1 is a high-performance analog mixed module designed for analog signal processing and hybrid control applications in industrial automation systems. It supports multiple analog signal inputs and outputs, featuring high precision, reliability, and strong anti-interference capabilities. It is widely used in industries such as power, metallurgy, chemicals, oil, and gas, and can be integrated into Distributed Control Systems (DCS) or Programmable Logic Controllers (PLC) for efficient data acquisition and control.
2. AX670 3BSE000566R1 Key Technical Parameters (关键技术参数)
| Parameter (参数) | Specification (规格) |
|---|---|
| Model (型号) | 3BSE000566R1 (AX670) |
| Function (功能) | 模拟信号输入/输出混合模块，支持多通道信号处理 |
| Input Channels (输入通道) | 8路模拟输入通道（支持电压/电流信号） |
| Output Channels (输出通道) | 4路模拟输出通道（支持电压/电流信号） |
| Signal Range (信号范围) | 输入：±10V、0-20mA、4-20mA；输出：±10V、0-20mA、4-20mA |
| Accuracy (精度) | 输入：±0.1% F.S.；输出：±0.1% F.S. |
| Resolution (分辨率) | 16位高精度ADC/DAC |
| Isolation (隔离) | 通道间/通道与电源间电气隔离，隔离电压≥1500VAC |
| Sampling Rate (采样率) | 每通道最大10kSPS（千次采样/秒） |
| Communication (通信) | 支持PROFIBUS-DP、Modbus等工业通信协议 |
| Power Supply (电源) | DC 24V ±10%，最大功耗≤15W |
| Operating Temperature (工作温度) | -20°C 至 +60°C |
| Storage Temperature (存储温度) | -40°C 至 +85°C |
| Protection Class (防护等级) | IP20（模块本体） |
| Dimensions (尺寸) | 120mm × 100mm × 30mm（长×宽×高） |
| Weight (重量) | 约0.5 kg |
| Approvals (认证) | CE、UL、CCC等国际认证 |
3. AX670 3BSE000566R1 Advanced Features (高级功能)
- 中文:
- 高精度信号处理：16位ADC/DAC分辨率，支持微小信号的精确采集与输出。
- 灵活配置：支持软件配置输入/输出范围、滤波参数及信号类型（电压/电流）。
- 抗干扰设计：电气隔离与电磁屏蔽技术，适用于强电磁干扰环境。
- 实时监控：支持快速采样率，满足动态过程控制需求。
- 故障诊断：内置自检功能，可检测通道故障、通信中断等异常。
- English:
- High-Precision Signal Processing: 16-bit ADC/DAC resolution for accurate acquisition and output of minute signals.
- Flexible Configuration: Supports software configuration of input/output ranges, filtering parameters, and signal types (voltage/current).
- Anti-Interference Design: Electrical isolation and electromagnetic shielding technology for use in environments with strong electromagnetic interference.
- Real-Time Monitoring: Supports fast sampling rates to meet dynamic process control requirements.
- Fault Diagnostics: Built-in self-test function detects channel faults, communication interruptions, and other anomalies.
4. AX670 3BSE000566R1 Application Fields (应用领域)
- 中文:
- 过程控制：化工、石油、天然气等行业的流量、压力、温度信号采集与控制。
- 能源管理：电力监控系统中的电能质量分析与谐波检测。
- 机械制造：数控机床、机器人系统中的高精度位置/速度控制。
- 环境监测：污水处理、空气质量监测等系统的模拟信号处理。
- English:
- Process Control: Flow, pressure, and temperature signal acquisition and control in industries such as chemicals, oil, and gas.
- Energy Management: Power quality analysis and harmonic detection in power monitoring systems.
- Machinery Manufacturing: High-precision position/speed control in CNC machines and robotic systems.
- Environmental Monitoring: Analog signal processing in wastewater treatment, air quality monitoring, and other systems.
5. Ordering Information (订货信息)
- Model (型号): 3BSE000566R1 (AX670)
- Catalog Number (目录编号): 需根据具体配置（如通信协议、防护等级）联系ABB获取。
- Optional Accessories (可选配件):
- 通信电缆：支持PROFIBUS-DP或Modbus协议的专用电缆。
- 防护外壳：IP67防护等级，适用于恶劣环境。
- 信号调理模块：适配不同量程的输入/输出信号。
6.AX670 3BSE000566R1 Technical Support & Warranty (技术支持与质保)
- 中文:
- 质保期：1年（自发货日起）。
- 技术支持：ABB全球服务网络提供24/7技术咨询与远程故障诊断。
- 软件支持：免费提供配置工具与文档，支持ABB Control Builder等软件集成。
- English:
- Warranty: 1 year from the date of shipment.
- Technical Support: ABB’s global service network offers 24/7 technical consulting and remote fault diagnosis.
- Software Support: Free provision of configuration tools and documentation, supporting integration with ABB Control Builder and other software.
