ABB CI810V1 (3BSE008584R1) Field Communication Interface Technical Specifications
（ABB CI810V1 现场通信接口技术参数）
1. Product Overview（产品概述）
- Model: CI810V1
- ABB Part Number: 3BSE008584R1
- Type: Field Communication Interface Module
- Function: Enables seamless communication between field devices (e.g., sensors, actuators) and the ABB AC800M controller system via industrial fieldbus protocols.
- Application: Industrial automation, process control, and distributed I/O systems.
（型号：CI810V1；ABB 部件号：3BSE008584R1；类型：现场通信接口模块；功能：通过工业现场总线协议实现现场设备与ABB AC800M控制器系统的无缝通信；应用：工业自动化、过程控制、分布式I/O系统。）
2. Key Technical Specifications（关键技术参数）
| Parameter（参数） | Specification（规格） |
|---|---|
| Communication Protocols（通信协议） | – Profibus DP – Modbus RTU (via optional firmware) – Supports master/slave modes |
| Bus Interface（总线接口） | RS-485 (2-wire, half-duplex) |
| Baud Rate（波特率） | 9.6 kbps to 12 Mbps (configurable) |
| Max. Nodes（最大节点数） | Up to 125 devices (Profibus DP) |
| Power Supply（电源供应） | 24 VDC (18–32 VDC range) – Consumption: Max. 1.5 W |
| Operating Temperature（工作温度） | -20°C to +60°C (-4°F to +140°F) |
| Storage Temperature（存储温度） | -40°C to +85°C (-40°F to +185°F) |
| Humidity（湿度） | 5% to 95% RH (non-condensing) |
| Mechanical Dimensions（机械尺寸） | – Width: 45 mm – Height: 130 mm – Depth: 120 mm – Mounting: DIN rail or panel mount |
| Weight（重量） | Approx. 250 g |
| Isolation（隔离） | 1.5 kV (bus-to-power isolation) |
| Certifications（认证） | – CE, UL, cUL, ATEX (optional) – IEC 61131-2 compliant |
3. Features & Benefits（功能与优势）
- High-Speed Communication（高速通信）
- Supports Profibus DP at up to 12 Mbps for real-time data exchange.
- （支持高达12 Mbps的Profibus DP通信，实现实时数据交换。）
- Flexible Protocol Support（灵活的协议支持）
- Configurable for Profibus DP or Modbus RTU, adapting to diverse industrial environments.
- （可配置为Profibus DP或Modbus RTU协议，适应不同工业环境。）
- Robust Design（坚固设计）
- Wide temperature range (-20°C to +60°C) and industrial-grade shock/vibration resistance.
- （宽温工作范围，抗冲击/振动能力强。）
- Easy Integration（易于集成）
- DIN rail mounting and compatibility with ABB AC800M controllers.
- （支持DIN导轨安装，兼容ABB AC800M控制器。）
- Redundancy Support（冗余支持）
- Optional redundant power supply and bus connections for high-availability systems.
- （可选冗余电源和总线连接，适用于高可用性系统。）
4. Applications（应用场景）
- Process Automation（过程自动化）
- Connecting sensors, valves, and actuators in chemical, oil & gas, and power plants.
- （连接化工、油气、电力行业的传感器、阀门和执行器。）
- Factory Automation（工厂自动化）
- Integration with PLCs and robots for manufacturing lines.
- （与PLC和机器人集成，用于生产线。）
- Infrastructure（基础设施）
- Water/wastewater treatment, HVAC, and transportation systems.
- （水处理、暖通空调、交通系统。）
5. Ordering Information（订购信息）
- ABB Part Number: 3BSE008584R1
- Optional Accessories（可选配件）:
- Profibus DP termination resistor (3BSE008585R1)
- Modbus RTU firmware license (3BSE008586R1)
- ATEX-certified enclosure (3BSE008587R1)
6. Warranty & Support（保修与支持）
- Warranty Period（保修期）: 2 years from delivery.
- Technical Support（技术支持）: ABB Global Customer Service (available 24/7).
Conclusion（总结）
The ABB CI810V1 (3BSE008584R1) is a high-performance field communication interface designed for reliable, high-speed data exchange in industrial environments. Its support for Profibus DP and Modbus RTU, combined with rugged design and easy integration, makes it ideal for demanding automation applications.
（ABB CI810V1 (3BSE008584R1) 是一款高性能现场通信接口，专为工业环境中的可靠、高速数据交换而设计。其支持Profibus DP和Modbus RTU协议，结合坚固的设计和易于集成的特性，使其成为苛刻自动化应用的理想选择。）
For further details, refer to the ABB AC800M Hardware Manual or contact your local ABB representative.
（更多详情，请参阅《ABB AC800M硬件手册》或联系当地ABB代表。）
